Atlas Filtri Hydra 7 inch M RLH 1 inch 90 mic pressure gauge

Atlas Filtri® Hydra M 1" RLH 90µm - well water filter

The Atlas Filtri® Hydra M 1" RLH 90µm water filter is equipped with a backwash - self-cleaning system and additionally with two pressure gauges.

This complete filter with two pressure gauges is ideal for filtering tap water and well water. It can be installed directly at the house water inlet or directly in front of a water pump. The self-cleaning system makes the filter quick and easy to clean, so it's ready for use again in no time. Protect your appliances and pipes! The Hydra water filter is designed to deliver high water flow with low pressure loss. The water filtration system filters out sand, suspended solids, and rust. This single-stage water filter is very space-saving and easy to install. The Hydra well water filter features a drain funnel/backflow protection to protect your drinking water supply.

Technical data

• Dimensions: 445 x 120 x 107 mm (H x W x D)
• Connection: IN / OUT connection made of brass
• Maximum pressure: 8.0 bar
• Maximum temperature: 45° C
• Lifespan: 12-24 months
• Pressure gauge: Radial type, with a pressure range: bar 0-12 or PSI 0-170
• Model: RA6000112
• EAN: 4260303251950
• Made in Italy

Filtration

• RLH - Prefilter cartridge
• Self-cleaning pre-filter cartridge - RLH: 90 µm
• Sand, rust, lime particles, scale, suspended matter, fine particles up to 90µm
• Lifespan: 12-24 months
• 7" filter dimensions: 173 x 70 x 30 mm
• Max. recommended flow rate 6000 l/h

Application

• Water treatment of drinking water
• Pre-filtration of well water, groundwater, wastewater
• Garden filters, cistern filters, sand filters, pump pre-filters
• Building services, domestic water filters, device protection filters - Installation in front of the water pump
• Device protection filters, protection of fittings, boilers, pumps, water tanks
• to protect washing machines and other technical equipment and pipes
• Installation: directly at the house water inlet or directly behind the water pump

Instructions for use

• Please open the drain valve of the Hydra filter slowly, as the filter cartridge may rupture due to the very high water pressure.
• If the drain valve is opened too quickly, the cartridge will hit the bottom very hard and may crack if cleaned frequently.
