Atlas Filtri Hydra 7 inch RSH 50 mic

Atlas Filtri® Hydra RSH 50µm backwash cistern water filter

The Atlas Filtri® Hydra RSH 50µm water filter is equipped with a backwash - self-cleaning system.

This complete filter is ideal for filtering tap water , cistern water , and well water . It can be installed directly at the house water inlet or directly in front of a water pump. The self-cleaning system makes the filter quick and easy to clean. The integrated, high-quality, extremely sturdy filter insert from Atlas Filtri® is made of plastic with washable plastic lamellas and can be easily cleaned under running water. This means that this filter insert can be reused multiple times and has a long service life. The 7" RSH filter insert with a 50µm filter unit is ideal as an equipment protection filter , for example as a pre-filter in front of a water pump or as a well water filter or even a cistern filter and sediment filter. The Hydra RSH water filter has a drain funnel/backflow protection to protect the drinking water supply.

Connection size to choose from

• 3/4" internal thread (max. recommended flow rate 5000 l/h)
  • RA6000020
  • EAN: 8021647114594
• 1" internal thread (Max. recommended flow rate 6000 l/h)
  • RA6000021
• 1" 1/2 internal thread ( Max. recommended flow rate 10000 l/h)

Technical data

• Dimensions: 390 x 120 x 107 (H x W x D in mm)
• Connection: IN/OUT connection made of brass
• Max. operating pressure: 8 bar (116 psi).
• Min. operating pressure: 1.8 bar (26 psi).
• Maximum temperature: 45° C

Filtration

• RSH - pre-filter cartridge
• Self-cleaning pre-filter cartridge with pleated plastic mesh RSH: 50 µm
• Filters sand, rust, limescale particles, scale, suspended matter and other particles larger than 50 µm
• Lifespan: approx. 12-24 months
• 7" filter dimensions: 173 x 70 x 30 mm

Application

• Water treatment of drinking water
• Pre-filtration of well water, groundwater, wastewater
• Ideal for use as a pre-filter, well water filter , cistern filter, sand filter, pump filter
• Device protection filter - installation in front of the water pump
• Building services, domestic water filters
• to protect washing machines and other technical equipment and pipes
• Installation: directly at the house water inlet or directly behind the water pump
• Device protection filters, protection of fittings, boilers, pumps, water tanks
