High pressure switch Quick 1/4"

High pressure switch Quick 1/4" - (HP) high pressure

The Quick 1/4" high pressure switch is used to control a booster pump or to fill a pressure tank of reverse osmosis systems. The high-pressure switch operates in a range of 15 PSI to 45 PSI, which corresponds to a pressure of approximately 1 bar to 3 bar. This means that the HP switch (high pressure switch) shuts off the pump or system below 1 bar and above 3 bar . Within 1-3 bar, the HP switch is switched on, and the pump or system is in operating mode.

Adjusting the high pressure switch - readjusting

It may happen that the pressure conditions within the reverse osmosis system change. With the HP switch, you have the option of adjusting or setting the pressure yourself. Please turn the grub screw carefully, only 1/4 turn at a time , and then check your system to see if it starts up properly and shuts down promptly. If necessary, you can repeat this process until the system is working correctly.

Note: If the grub screw is turned out as far as it will go (counterclockwise), the HP switch will activate at 1 bar. Please do not completely unscrew the grub screw, as this will cause water to leak from the HP switch! If the grub screw is turned in (clockwise), the HP switch will only activate at 3 bar. All HP switches are factory set to an average value.

Technical data

• HP switch for reverse osmosis systems with pressure booster pump
• universally suitable for 24V and 36V systems
• regulates the shutdown of the booster pump on an osmosis system
• Switching threshold: 1 bar or 3 bar preset
• adjustable using the grub screw
• Connection: 1/4" x 1/4" (6.35 mm) quick connection for the hose
• Mains connection: 2 x flat plugs for cable connection
• Dimensions: 75 x 51 x 27 (L x H x W in mm)
• Color: white
• Material: Polypropylene PP
• suitable for drinking water
• Item weight: 45g
